Acer Aspire 4520

Aspire 4520 Series Specifications


Part Number: Aspire4520 Aspire 4520

Feature Description

Part Number Varies by model

Processor / Speed AMD Turion 64 X2 dual-core mobile technology TL-66/TL-64/TL-60/TL-58/TL-56 TL-52 (2x 512 MB L2 cache, 2.30/2.20/2/1.90/1.80/1.60 GHz, 1600 MHz HyperTransport Bus),

AMD Turion 64 mobile technology MK-36/MK-38 (512 KB L2 cache, 2/2.20 GHz,), supporting AMD PowerNow! technology and AMD HyperTransport technology or

AMD Athlon 64 X2 dual-core mobile technology TK-53/TK-55 (2x 256 KB L2 cache, 1.70/1.80 GHz), supporting AMD PowerNow! technology and AMD HyperTransport technology

Core Logic Chipset NVIDIA nForce 610M Media and Communication Processor (MCP)

System Bus Speed

RAM / Max RAM Up to 2 GB of DDR2 667 MHz memory, upgradeable to

4 GB using two soDIMM modules (dual-channel support)

Video Subsystem NVIDIA GeForce 7000M integrated 3D graphics with up to 752 MB of TurboCache (256 MB of dedicated system memory, up to 496 MB of shared system memory), supporting Microsoft DirectX 9

LCD Properties 14.1" WXGA high-brightness (200-nit) Acer CrystalBrite TFT LCD, 1280 x 800 pixel resolution or

14.1" WXGA high-brightness (200-nit) TFT LCD, 1280 x 800 pixel resolution

Hard Disk Drive up to 250 GB Hard Disk Drive

Optical Drive 8X DVD-Super Multi or DVD/CD-RW Combo

(varies by model)

Battery, Primary 44.4W 4000 mAh 6-cell Lithium Ion battery pack

2.5-hour battery life

Sound Subsystem Dolby-certified surround sound system with two built-in stereo speakers

S/PDIF (Sony/Philips Digital Interface) support for digital speakers

MS-Sound compatible, Built-in microphone

PCCard Support 1 ExpressCard/54 slot

Pointing Device Touchpad

Peripheral Subsystem 4 USB 2.0 ports, 1 IEEE 1394 port, 1 VGA port,

1 S-video/TV-out (NTSC/PAL) port,

5-in-1 card reader (SD, MMC, MS, MS PRO, xD)

Headphone/speaker/line-out jack with S/PDIF support

Microphone-in jack/Line-in jack



Integrated Acer Crystal Eye webcam, supporting enhanced Acer PrimaLite technology

1 CIR port (varies by model)

Modem 56K ITU V.92 PPT approved, Wake-on-Ring ready

Ethernet Gigabit Ethernet, Wake-on-LAN ready

Acer InviLink and 802.11b/g Wi-Fi CERTIFIED network connection, supporting Acer SignalUp wireless technology

Bluetooth 2.0+EDR Enhanced Data Rate (varies by model)

Dimensions / Weight 44.4W 4000 mAh 6-cell Li-ion battery pack

2.5-hour battery life

AC Power 100-240V AC AutoSensing Adapter



Environment

Shock

Operational/Non-Operational

5 G max. pulse / 40 G max. pulse

Vibration

Non-Operational

5-27HZ, 0.16" p-p, 2g peak, 27-500HZ

Temperature

Operational/Non-Operational

+5ºC - +35ºC / -20ºC - +50ºC

Humidity

Operational/Non-Operational

10% - 90% / 10% - 90%

Altitude

Operational/Non-Operational

10,000 ft / 40,000 ft

Operating System Windows XP Professional with Service Pack 2

Windows XP Home with Service Pack 2

Windows Vista Home Premium

Windows Vista Home Basic

(varies by model)

Drivers:

BTW_ 6.0.1.4900_Vistax86.zip
Camera_Bison_7.32.701.12_Vistax86.zip
Camera_Suyin_5.7.29.500_Vistax86.zip
CardReader_RICOH_v3.52.02 _Vistax86.zip
Chipset_NVIDIA_13.13_XPx86.zip
CIR_Winbond_7.1.64.1010_XPx86.zip
